Realstar Compatible Machine Parts

Remanufactured diaphragm vacuum pump 0719015 for FMB / Firbimatic, Union, and Realstar dry-cleaning machine distillation systems.

This vacuum pump is used in the machine distillation circuit to create the vacuum needed for proper distillation and solvent recovery. Vacuum leaks, worn vacuum seals, incorrect pump configuration, or a weak pump/motor assembly can reduce recovery rate, make the system work harder, and eventually lead to pump or motor failure.

Use this listing when the installed pump, motor plate, machine manual, and service records match the FMB / Firbimatic, Union, or Realstar references below. Before ordering, compare the part numbers, motor voltage/phase/frequency, pump plate, mounting, plumbing orientation, and machine model.

Technical Specifications

Remanufactured air-cooled diaphragm vacuum pump assembly for dry cleaning machine service applications. Verify fitment against the installed component, machine data plate, and service manual before ordering.

• Manual-backed FMB / Firbimatic reference: 0719015; vacuum pump PAV71S400; 0.37 kW; 50/60 Hz; air-cooled.

• Observed pump-head marking from supplied photo: hyco ML-348-D37-SA; type P-173/2; Trumpf Id.-Nr. 352561.

• Observed motor marking from supplied photo: hyco 3-phase motor; Type 7AA71M-4 B34; IP55; IEC 38 / EN 60034.

• Motor rating: 0.37/0.43 kW, approximately 1/2 HP class; S1 duty; insulation class F.

• Speed: 1370/1670 1/min for 50/60 Hz operation.

• Voltage: 230/400V delta/wye at 50 Hz; 460V wye at 60 Hz.

• Current: 1.78/1.03A at 50 Hz; 1.02A at 60 Hz.

• Power factor: cos phi 0.80/0.78.

• Motor manufacturer reference: made by Siemens/CZ; Type 1LA7; UL File No. E227216.

• Direction arrow is present on the motor housing. Confirm rotation, voltage, phase, mounting, pump-head marking, and plumbing orientation before ordering.

• Observed pump serial field is present but not used for fitment confirmation because the handwritten marking is not legible from the supplied photo.

Part Numbers & Cross References

Use this section to separate direct brand part numbers from cross-reference and verification references for this remanufactured diaphragm vacuum pump. Always verify the installed pump, motor plate, machine model, voltage, phase, frequency, mounting, plumbing orientation, and service manual before ordering.

Part Numbers

FMB / Firbimatic

• 0719015

• 071-9015

• PAV.71.S4.00

• 0719142

• 0719005

• 0719053

• 0719070

• 32-50

• M17726

Union

• PU0719015

• PU071905

• 071905

• 0719005

• 0719142

• M17726

Realstar

• 0719005

• 071905

Cross References

FMB / Firbimatic

• Union cross-reference: PU0719015.

• Realstar comparison references: 0719005 and 071905 should be compared against FMB / Firbimatic 0719015 / 071-9015 through the machine model, installed pump, and service manual.

• Air-cooled vacuum pump motor reference: 0719142.

• Observed old-site listing context: FMB / Firbimatic air-cooled vacuum pump motor, 220V, 3 phase, 60 Hz.

• Manufacturer / pump assembly references: PAV.71.S4.00, Bermar Air Cooled, Bonora, Due Effe PV75, hyco ML-348-D37-SA, hyco P-173/2.

• Related vacuum-pump family references for verification only: 0719005, 0719053, 0719070, M17726, and 32-50 appear in nearby vacuum-pump/motor family evidence. Do not treat these as direct substitutes unless the installed pump, motor, cooling style, voltage, and manual match.

Union

• FMB / Firbimatic cross-reference: 0719015.

• Formatted cross-reference: 071-9015.

• Realstar comparison references: 0719005 and 071905.

• Air-cooled pump motor cross-reference: 0719142.

• Union old-site listing context: air-cooled vacuum pump motor covering 0719142 / PU0719015 / 0719015, 220V, 3 phase, 60 Hz.

• Related Union family reference for verification only: PU071905 appears in the liquid-cooled vacuum pump motor family and should not be used as a direct substitute without confirming the installed assembly.

Realstar

• FMB / Firbimatic cross-reference: 0719015.

• Formatted FMB / Firbimatic cross-reference: 071-9015.

• Union cross-reference: PU0719015.

• Air-cooled pump motor cross-reference: 0719142.

• Realstar application note: use the Realstar machine model, installed component markings, horsepower, voltage, pump/motor plate, and service manual to confirm the correct pump before ordering.

Component Markings For Verification

These markings are listed for identification and verification. They are not presented as separate brand part numbers.

• Pump head: hyco ML-348-D37-SA.

• Pump type: P-173/2.

• Trumpf Id.-Nr.: 352561.

• Motor: hyco 7AA71M-4 B34.

• Motor manufacturer/reference: Siemens/CZ Type 1LA7; UL File No. E227216.

• Observed motor service context: 0.37/0.43 kW, 50/60 Hz, 230/400V at 50 Hz and 460V at 60 Hz.

Machine Fitment

Model-number reference for this remanufactured diaphragm vacuum pump across the shared FMB / Firbimatic, Union, and Realstar dry cleaning machine lineage. Use the brand sections below for model matching, then verify the installed pump plate, motor plate, voltage, phase, frequency, rotation, mounting, plumbing orientation, and service manual before ordering.

FMB / Firbimatic Models

• ECOPRO 915; ECOPRO 915S; ECOPRO 918; ECOPRO 918S; ECOPRO AM918.

• SAVER 35; SAVER 350; SAVER 35P; SAVER 350P; SAVER 40; SAVER 40P; SAVER 80SM; SAVER HYDROCARBON.

• F AS 18 LT2; F AS 18 ST2; F18 LT2; F18 LT3; F18 ST2; AXIAL 40; AXIAL 918; AXIAL 925; AXIAL-918.

• ECOGREEN 35; ECOGREEN 50; ECOGREEN 80; ECOGREEN 95; ECOGREEN 95SM; ECOGREEN DC; ECOGREEN L2118; ECOGREEN S2118; ECOGREEN L2120; ECOGREEN L2125; ECOGREEN L2132; ECOGREEN L2140; ECO GREEN 60; ECO GREEN 95.

• ECOLINE; ECOLINE 16; ECOPRO AM; L 18; L-250; L750; L2118; AM2118; S2118; P16; P1567; P1705; P6241; T1838; VORTEX 40; VORTEX 50; VORTEX 80; VORTEX L2018; VORTEX S2018; VORTEX PRIMARY.

• Manual/reference numeric model set: 035; 05; 068; 08; 09; 10; 100; 12; 120; 13; 130; 14; 15; 153; 16; 20; 208; 220; 23; 24; 25; 30; 306; 310; 32; 338; 340; 35; 36; 37; 40; 410; 45; 465; 473; 50; 520; 60; 600; 63; 70; 71; 724; 765; 80; 895; 896; 918; 95.

• Factory/model references observed in recovered manual matrix: HC7-18-CL; HC7-18-CLM; HC7-18-CS; HC8-18-CL; HC8-18-CLM; HC8-18-CS.

Union Models

• HXP8018C; L840; P840.

• HL840K; HP840K; HXL8018K.

• HL850K; HP850K; HL860K; HP860K; HXL8025K; HL880K; HXL8032K; HL890K.

• Union cross-family applications equivalent to the FMB / Firbimatic 915, 915S, 918, AM918, L2118, AM2118, and S2118 lineage when the installed diaphragm vacuum pump assembly and service documentation match.

Realstar Models

• KM315; KM315-K4; KT215; KT215-K4.

• KM343; KM343-K4; KT343; KT343-K4.

• KM403; KM403-K4; KT403; KT403-K4; KM503; KM503-K4; KT503; KM703; KM703-K4; KM803; KM803-K4.

• KM-36; RKM36; KM-340; RKM340; KM-400; RKM400.

Ordering Verification

Confirm the part number, installed component markings, voltage or pressure rating where applicable, connection size, mounting style, and machine model before ordering.

Contact Corbett Equipment if you need help matching the part to a Firbimatic, Union, Realstar, or related FMB machine.

This Danfoss WVX / WVF15-style 1/2 inch pressostatic water valve is used in compatible FMB / Firbimatic, Union, and Realstar dry cleaning machine refrigeration and water-control systems.

The valve helps regulate condenser water flow in response to refrigeration pressure so the machine can maintain proper cooling, recovery performance, and stable refrigeration operation.

Use this listing when the original machine part number, valve size, body markings, pressure-control arrangement, fittings, and service manual match 0913002 / F6528.

Technical Specifications

• Component type: 1/2 inch pressostatic / pressure-operated water regulating valve.

• Valve family: Danfoss WVX / WVF15 / WVi5-style 1/2 inch water valve, with older FMB/FM manual references to WYF15 D.1/2.

• Primary application: refrigeration condenser water-control service on compatible FMB / Firbimatic, Union, and Realstar dry cleaning machines.

• Function: regulates condenser water flow in response to refrigeration pressure to support cooling, recovery performance, and stable refrigeration operation.

• Nominal size: 1/2 inch. Verify the installed valve body, fittings, pressure-control arrangement, and machine service manual before ordering.

• Confirmed price-list description: 1/2 inch Danfoss WVX Water Valve / Water Valve Refrigeration.

• Companion 3/4 inch pressostatic valve: 0913003 / F13623. Do not substitute the 3/4 inch valve for this 1/2 inch listing unless the machine manual and installed component confirm it.

• Nearby thermostatic valve references 0914002 / V13841 and 0914004 / V1566 are different components and are not substitutes for this listing.

Part Numbers & Cross References

Use this section to separate direct brand part numbers from cross-reference and legacy/manual references. Always verify the installed component, valve size, body markings, fittings, pressure-control arrangement, and service manual before ordering.

Part Numbers

FMB / Firbimatic

• 0913002

• 09.13.002

• F6528

• F8526

Union

• 0913002

• 09.13.002

Realstar

• 0913002

Cross References

FMB / Firbimatic

• Legacy price-list cross-reference: F6528, described as a 1/2 inch Danfoss WVX Water Valve / Water Valve Refrigeration.

• Manual-page legacy reference: F8526 appears in older FMB/FM valve-table material for pressostatica tipo WYF15 D.1/2. Confirm against the installed component and manual before substitution.

• Valve-family wording found in manuals: Danfoss WVX, WVF15, WVi5, and WYF15-style 1/2 inch pressostatic water valve references.

Union

• FMB / Firbimatic cross-reference: 0913002.

• Formatted manual-style reference: 09.13.002.

• Legacy FMB / Firbimatic references for verification: F6528 and F8526 when the Union machine manual, installed valve, and valve size match.

Realstar

• FMB / Firbimatic cross-reference: 0913002.

• Legacy FMB / Firbimatic references for verification: F6528 and F8526 when the Realstar machine manual, installed valve, and valve size match.

Related Parts To Verify Separately

• 0913003 / F13623 is the companion 3/4 inch pressostatic valve.

• 0914002 / V13841 and 0914004 / V1566 are thermostatic valve references, not this 1/2 inch pressostatic water valve.

Machine Fitment

Model-number reference for this 1/2 inch Danfoss pressostatic water valve across the shared FMB / Firbimatic, Union, and Realstar dry cleaning machine lineage. Use the brand sections below for model matching, then verify the installed valve, machine data plate, fittings, and service manual before ordering.

FMB / Firbimatic Models

• Eco-15LT3; Eco-15LT-3.

• Ecopro L2118; L2118-series.

• Axial general spare-parts family; AXIAL 40; AXIAL 918; AXIAL 925; AXIAL-918.

• ECO PRO 918; ECOGREEN 35; ECOGREEN 50; ECOGREEN 80; ECOGREEN 95; ECOGREEN 95SM; ECOGREEN DC; ECO GREEN 60; ECO GREEN 95.

• ECOLINE; ECOLINE 16; ECOPRO AM; L 18; L-250; L750; P16; P1567; P1705; P6241; SAVER 80SM; SAVER HYDROCARBON; T1838; VORTEX 40; VORTEX 50; VORTEX 80; VORTEX PRIMARY.

• Manual/reference numeric model set: 035; 05; 068; 08; 09; 10; 100; 12; 120; 13; 130; 14; 15; 153; 16; 20; 208; 220; 23; 24; 25; 30; 306; 310; 32; 338; 340; 35; 36; 37; 40; 410; 45; 465; 473; 50; 520; 60; 600; 63; 70; 71; 724; 765; 80; 895; 896; 918; 95.

• Factory/model code reference: HC7-18-CL.

Union Models

• HL-780.

• HL-860.

• L740S.

• L750.

• RS-102.

• RS-122.

• RS-152.

• Related lineage context: HXP8018C; L840; P840.

Realstar Models

• KM-340; RKM340.

• Related lineage context: KM315; KM315-K4; KT215; KT215-K4.

• Related lineage context: KM343; KM343-K4; KT343; KT343-K4.

Ordering Verification

Confirm the part number, installed valve markings, valve size, fitting style, pressure-control arrangement, and machine model before ordering.

Confirm this is the 1/2 inch pressostatic water valve before replacing it. The nearby 3/4 inch pressostatic valve and thermostatic water valves are different parts.

For FMB / Firbimatic, Union, and Realstar machines, match the listing against the machine data plate, service manual table, installed component markings, and physical valve/fitting configuration.

Contact Corbett Equipment if you need help matching the valve to a FMB / Firbimatic, Union, Realstar, or related FMB-lineage dry cleaning machine.

This still float safety switch, part 0315001, is used in the still/distillation level safety circuit on compatible FMB / Firbimatic, Union, and Realstar dry cleaning machines.

The switch helps monitor the level condition in the still or distiller area and provides a safety/control signal so the machine can avoid unsafe still operation when the float signal or liquid level is not correct.

Use this listing where the original machine record, installed component, and service manual match 0315001, old FMB / Firbimatic A5981, or C1400003. Before ordering, compare the installed switch, float/rod assembly, wiring, mounting, and manual table reference.

Technical Specifications

• Component type: still/distiller level safety float switch.

• Service function: float-operated level safety/control signal for the still or distillation section.

• Common listing description: Still Level Safety Float Switch.

• Additional manual/price-list wording: Still Float Switch, Still Float, Floating Level Control, and Interruttore a Galleggiante.

• Primary FMB / Firbimatic part reference: 0315001.

• Legacy FMB / Firbimatic reference: A5981.

• Component/reference number found with this listing: C1400003.

• Manual table context: 4-CEL 0315001. Related rod/float assembly reference 2-ASTA 40A763/PGT may help physical verification, but must be checked against the installed assembly before ordering.

• Do not substitute nearby level/float references such as 0315008, 0315013, 0315014, 0315015, 0315017, or 0315018 unless the machine manual and installed component confirm the match.

Part Numbers & Cross References

Use this section to separate direct part numbers from cross-reference and verification notes. Always confirm the installed component, machine manual, still/distiller location, wiring, mounting, and physical float/rod arrangement before ordering.

Part Numbers

FMB / Firbimatic

• 0315001

• 031-5001

• A5981

• C1400003

• 4-CEL

Union

• 0315001

• 031-5001

Realstar

• 0315001

• 031-5001

Cross References

FMB / Firbimatic

• Old FMB / Firbimatic reference A5981 is listed with 0315001 as Still Float Switch / Still Level Safety Float Switch.

• C1400003 appears as a component/reference number tied to the Still Level Safety Float Switch description.

• Manual wording includes 4-CEL 0315001 and Interruttore a Galleggiante for the float-switch table entry.

• 2-ASTA 40A763/PGT is a related rod/assembly context reference for physical verification only; do not treat it as a substitute part without matching the installed assembly.

Union

• Union manual/OCR records show 0315001 in still/distiller table contexts. Compare against FMB / Firbimatic 0315001, old A5981, and C1400003 when the installed switch and machine manual match.

Realstar

• Realstar manual/OCR records show 0315001 in KM/RKM, M/RM, and RS-series contexts. Compare against FMB / Firbimatic 0315001, old A5981, and C1400003 when the installed switch and machine manual match.

Machine Fitment

Model-number references for still/distillation float safety switch 0315001 across the shared FMB / Firbimatic, Union, and Realstar dry cleaning machine lineage. Use the model list below as a research-backed fitment guide, then verify against the installed part and service manual before ordering.

FMB / Firbimatic Models

• Eco-15LT3 / Eco-15LT-3.

• Coal Perc 121 / CP-121.

• FMB / Firbimatic still or distillation assemblies that call for 0315001, A5981, or C1400003.

Union Models

• HL-780 / HL780.

• HL-840 / HL840.

• HL-850 / HL850.

• HL-860 / HL860.

• HL-880 / HL880.

• HL-890 / HL890.

• L740S.

• L740 / HL740 / L 740-840.

• P840 / P850.

Realstar Models

• KM-400 / RKM400.

• KM-500 / RKM500.

• KM-700 / RKM700.

• KM-800 / RKM800.

• M-400 / RM400-2 / M400-RSM400.

• M-500 / RM500.

• M-700 / RM700 / M700-RSM700.

• M-800 / RM800 / M800-RSM800.

• RS-102 / RS-103 / RS-122 / RS-123 / RS-152 / RS-153.

• RS-102E / RS-122E / RS-152E.

Ordering Verification

Confirm the installed part number, legacy A5981 reference, C1400003 reference, visible component markings, physical float/rod arrangement, wiring, connector style, mounting, and still/distiller location before ordering.

Match the machine data plate and service manual table against the installed switch. This listing is for the still float safety switch / floating level control, not the other nearby short/long float switches or preseparator level controls.

For FMB / Firbimatic, Union, and Realstar machines, compare photos of the installed component and the manual exploded-view/table reference. Contact Corbett Equipment if you need help verifying the correct switch before ordering.

This Rovel 1/2 inch normally closed air-operated valve, part 0901083, is used as a pneumatic and fluid-control valve on compatible FMB / Firbimatic, Union, and Realstar dry cleaning machines.

The valve is a single-acting normally closed gate-style valve. In the rest position the valve remains closed; when actuated by air pressure it opens to allow the machine circuit to flow.

The product label identifies the component as VALVOLA VATAL 130 1/2", Cod. 1616, Comm. n° 255999, Made in Italy. Use this listing when the installed valve, machine manual, and service records match FMB / Firbimatic 0901083, Union PU0901083, or Realstar 0901083.

Technical Specifications

• Component type: 1/2 inch normally closed air-operated gate valve / pneumatic-fluid control valve.

• Brand / manufacturer marking: Rovel.

• Product label description: VALVOLA VATAL 130 1/2".

• Product label code: Cod. 1616.

• Product label commission/order marking: Comm. n° 255999.

• Barcode / label code: 1616255999. This is a 10-digit label barcode and is recorded as a barcode/reference code, not as a verified standard GTIN.

• Country of origin label: Made in Italy.

• Additional label marking: 93.

• Primary function: valve stays closed in the rest position and opens when actuated by compressed air.

• Valve family: single-acting normally closed gate-valve family.

• Nominal port size: 1/2 inch. Verify installed thread, fittings, actuator orientation, and valve body before ordering.

• Threading reference: GAS cylindrical 55 degrees UNI-ISO 228, where applicable to the installed valve body.

• Actuator type: single acting, normally closed.

• Actuator working pressure reference: minimum 5 bar, maximum 10 bar.

• Room temperature reference: 0 degrees C to 100 degrees C maximum.

• Shutter style: plates on conical seat.

• Material references: anodized aluminum 2011 alloy cylinder, AISI 303 stainless shaft, OT-58 brass valve body and shutter, and NBR sealing/contact material.

• Installation notes: avoid excessive thread stress, use proper thread sealing, lubricate through the pneumatic system, avoid knob-down mounting, and inspect seals/O-rings through the safety hole after heavy operating cycles.

• Size-specific dimensions must be verified from the installed part.

Part Numbers & Cross References

Use this section to separate direct brand part numbers from cross-reference and legacy references. Always verify the installed valve, port size, actuator configuration, fittings, machine model, and service manual before ordering.

Part Numbers

FMB / Firbimatic

• 0901083

• 221966

Union

• PU0901083

Realstar

• 0901083

Rovel Component Marking

• VALVOLA VATAL 130 1/2"

• Cod. 1616

• Comm. n° 255999

• Barcode / label code 1616255999

Cross References

FMB / Firbimatic

• Legacy reference: COD 11012.

• Legacy reference: COD 1868.

• Commercial reference: COMM 221966.

Union

• FMB / Firbimatic cross-reference: 0901083.

• Old / legacy reference: V18003 appears in Union/Firbimatic cross-reference evidence for this valve path.

Realstar

• FMB / Firbimatic cross-reference: 0901083.

• Union cross-reference: PU0901083.

• Realstar application note: verify against the installed valve, Realstar machine model, manual table, and shared FMB / Union / Realstar lineage before ordering.

Rovel

• Label match: VALVOLA VATAL 130 1/2", Cod. 1616, Comm. n° 255999, barcode / label code 1616255999.

Related Valve Family References

• 0901080 and 0901165 appear in nearby 1/2 inch N.C. valve family evidence. Treat them as related-family verification references, not automatic substitutes.

Machine Fitment

Model-number reference for this 1/2 inch normally closed air-operated valve across the shared FMB / Firbimatic, Union, and Realstar dry cleaning machine lineage. Use the brand sections below for model matching, then verify the installed valve, machine data plate, fittings, and service manual before ordering.

FMB / Firbimatic Models

• AXIAL 40; AXIAL 918; AXIAL 925; AXIAL-918.

• ECO PRO 918; ECOPRO AM; ECOGREEN 35; ECOGREEN 50; ECOGREEN 80; ECOGREEN 95; ECOGREEN 95SM; ECOGREEN DC; ECO GREEN 60; ECO GREEN 95.

• ECOLINE; ECOLINE 16; L 18; L-250; L750; P16; P1567; P1705; P6241.

• SAVER 80SM; SAVER HYDROCARBON; T1838; VORTEX 40; VORTEX 50; VORTEX 80; VORTEX PRIMARY.

• Manual/reference numeric model set: 035; 05; 068; 08; 09; 10; 100; 12; 120; 13; 130; 14; 15; 153; 16; 20; 208; 220; 23; 24; 25; 30; 306; 310; 32; 338; 340; 35; 36; 37; 40; 410; 45; 465; 473; 50; 520; 60; 600; 63; 70; 71; 724; 765; 80; 895; 896; 918; 95.

• Factory/model code reference: HC7-18-CL.

Union Models

• Union dry cleaning machine models and service assemblies that call for PU0901083.

• Related lineage context: HXP8018C; L840; P840.

• Verify Union fitment by matching PU0901083, valve size, valve orientation, and machine manual table.

Realstar Models

• Realstar dry cleaning machine models and service assemblies that use the shared FMB / Union / Realstar 0901083 valve lineage.

• Related lineage context: KM315; KM315-K4; KT215; KT215-K4; KM343; KM343-K4; KT343; KT343-K4.

• Verify Realstar fitment by matching 0901083, valve size, valve orientation, installed component markings, and machine manual table.

Ordering Verification

Confirm the installed valve is a 1/2 inch normally closed air-operated valve before ordering.

Match the part number path against FMB / Firbimatic 0901083 or 221966, Union PU0901083, Realstar 0901083, and legacy references such as COD 11012, COD 1868, COMM 221966, or V18003.

Compare the physical valve body, port size, thread/fitting arrangement, actuator and knob configuration, pneumatic air supply, machine model, and service manual before replacing the part.

Contact Corbett Equipment if you need help matching the valve to a FMB / Firbimatic, Union, Realstar, or related FMB-lineage dry cleaning machine.

Air Valve, 1 in, NC Complete | FMB 0901018 / Union 0901018 / RS 0901018.

One-inch normally closed air-operated valve 0901018 is a complete pneumatic valve assembly used on compatible FMB / Firbimatic, Union, and Realstar dry-cleaning machines.

This valve should be matched by port size, normally closed function, actuator arrangement, valve body, pneumatic supply, fittings, and machine manual.

Use this listing when the installed component and service records match FMB / Firbimatic 0901018, Union 0901018, Realstar 0901018, or the legacy references listed below.

Technical Specifications

• Component type: 1 inch normally closed air-operated valve.

• Primary system: pneumatic / valve-control circuit.

• Primary application: dry-cleaning machine service and repair.

• Verification points: 1 inch port size, normally closed operation, actuator style, valve body, fittings, pneumatic supply, mounting, and installed component markings.

• Evidence source: FMB, Union, and Realstar manual/database evidence for 0901018 and related legacy references.

Part Numbers & Cross References

Part Numbers

FMB / Firbimatic

• 0901018

• 0091018

• 220946

• 2317/11100

• 895/2317

Union

• 0901018

Realstar

• 0901018

Cross References

FMB / Firbimatic

• Legacy reference V12984

• Legacy reference G11100

• COD 11100

• COD 2317

• COD 675

• COD 895

• COMM 220946

Union

• FMB / Firbimatic cross-reference 0901018

Realstar

• FMB / Firbimatic cross-reference 0901018

• Union cross-reference 0901018

Machine Fitment

Model-number references below come from the Corbett Equipment FMB / Union / Realstar lineage database and should be verified against the machine data plate and service manual before ordering.

FMB / Firbimatic machine models

• ECOPRO 918

• F AS 18 LT2

• SAVER 40

Union machine models

• HXP8018C

• L840

• P840

Realstar machine models

• KM343

• KM343-K4

• KT343

• KT343-K4

Factory model-code reference: HC7-18-CL

Ordering Verification

Confirm the installed 1 inch normally closed valve, port size, actuator, fittings, legacy reference path, machine model, and service manual before ordering. Contact Corbett Equipment if you need help matching this valve to a FMB / Firbimatic, Union, Realstar, or related FMB-lineage machine.

Still Door Gasket Viton 402015/MTP Dry Cleaning Part 402015 / Old G13883.

Viton still-door gasket 402015 is used to seal the still door on compatible FMB / Firbimatic, Union, and Realstar dry-cleaning machine distillation systems.

A worn or incorrect still-door gasket can cause vapor, solvent, or vacuum sealing problems around the still door and can reduce proper distillation performance.

Use this listing when the installed gasket and service records match FMB / Firbimatic 402015, MTP, or legacy references G13883 / G13883A.

Technical Specifications

• Component type: still-door gasket / seal.

• Material reference: Viton.

• Primary system: still, distillation, heating, and solvent-recovery sealing.

• Primary application: dry-cleaning machine still-door service and repair.

• Verification points: gasket profile, still-door size, gasket material, machine model, and installed component dimensions.

• Evidence source: Firbimatic parts database/manual evidence for 402015 and legacy references G13883 / G13883A.

Part Numbers & Cross References

Part Numbers

FMB / Firbimatic

• 402015

Union

• Not confirmed in the current Corbett Equipment database. Verify by installed component and service manual.

Realstar

• Not confirmed in the current Corbett Equipment database. Verify by installed component and service manual.

Cross References

FMB / Firbimatic

• MTP

• Legacy reference G13883

• Legacy reference G13883A

Union

• Verify by shared FMB / Union still-door lineage, gasket dimensions, and Union service manual.

Realstar

• Verify by shared FMB / Realstar still-door lineage, gasket dimensions, and Realstar service manual.

Machine Fitment

Model-number references below come from the Corbett Equipment FMB / Union / Realstar lineage database and should be verified against the machine data plate and service manual before ordering.

FMB / Firbimatic machine models

• ECOPRO 918

• F AS 18 LT2

• SAVER 40

Union machine models

• HXP8018C

• L840

• P840

Realstar machine models

• KM343

• KM343-K4

• KT343

• KT343-K4

Factory model-code reference: HC7-18-CL

Ordering Verification

Confirm the installed still-door gasket profile, material, door size, machine model, and service manual before ordering. Contact Corbett Equipment if you need help matching this gasket to a FMB / Firbimatic, Union, Realstar, or related FMB-lineage machine.

Danfoss Orifice #2 Dry Cleaning Part 0918066 / Old F8008.

Danfoss orifice #2, part 0918066, is a refrigeration-metering insert used with compatible Danfoss expansion-valve assemblies on FMB / Firbimatic, Union, and Realstar dry-cleaning machines.

This small part must be matched to the mating valve body and refrigeration application, because an incorrect orifice can affect evaporator feed, cooling performance, and recovery behavior.

Use this listing when the installed orifice and service records match FMB / Firbimatic 0918066 or old reference F8008.

Technical Specifications

• Component type: Danfoss refrigeration valve orifice insert.

• Orifice size: #2.

• Primary system: refrigeration circuit.

• Primary application: dry-cleaning machine refrigeration service and repair.

• Verification points: Danfoss valve family, orifice size, mating expansion-valve body, refrigerant circuit, and installed component markings.

• Evidence source: Corbett recovered product database for 0918066 and old reference F8008.

Part Numbers & Cross References

Part Numbers

FMB / Firbimatic

• 0918066

• F8008

Union

• Not confirmed in the current Corbett Equipment database. Verify by installed component and service manual.

Realstar

• Not confirmed in the current Corbett Equipment database. Verify by installed component and service manual.

Cross References

FMB / Firbimatic

• Old reference F8008

Union

• Verify by shared FMB / Union refrigeration-system lineage and installed Danfoss orifice.

Realstar

• Verify by shared FMB / Realstar refrigeration-system lineage and installed Danfoss orifice.

Machine Fitment

Model-number references below come from the Corbett Equipment FMB / Union / Realstar lineage database and should be verified against the machine data plate and service manual before ordering.

FMB / Firbimatic machine models

• ECOPRO 918

• F AS 18 LT2

• SAVER 40

Union machine models

• HXP8018C

• L840

• P840

Realstar machine models

• KM343

• KM343-K4

• KT343

• KT343-K4

Factory model-code reference: HC7-18-CL

Ordering Verification

Confirm the installed Danfoss valve family, #2 orifice size, mating valve body, refrigeration circuit, machine model, and service manual before ordering. Contact Corbett Equipment if you need help matching this orifice to a FMB / Firbimatic, Union, Realstar, or related FMB-lineage machine.

Danfoss TX2 Thermostatic Expansion Valve - PN 0912018.

Danfoss TX2 thermostatic expansion valve 0912018 is used in the refrigeration system on compatible FMB / Firbimatic, Union, and Realstar dry-cleaning machines.

The expansion valve meters refrigerant flow and should be matched to the installed valve body, sensing element, orifice arrangement, refrigerant application, and machine manual.

Use this listing when the installed component and service records match FMB / Firbimatic 0912018.

Technical Specifications

• Component type: Danfoss TX2 thermostatic expansion valve.

• Primary system: refrigeration circuit.

• Primary application: dry-cleaning machine refrigeration service and repair.

• Verification points: valve body, TX2 marking, orifice compatibility, refrigerant circuit, sensing bulb/capillary arrangement, fittings, and installed component markings.

• Evidence source: Firbimatic parts database/manual evidence for 0912018.

Part Numbers & Cross References

Part Numbers

FMB / Firbimatic

• 0912018

Union

• Not confirmed in the current Corbett Equipment database. Verify by installed component and service manual.

Realstar

• Not confirmed in the current Corbett Equipment database. Verify by installed component and service manual.

Cross References

FMB / Firbimatic

• Danfoss TX2 expansion valve application.

Union

• Verify by shared FMB / Union refrigeration-system lineage and installed Danfoss valve.

Realstar

• Verify by shared FMB / Realstar refrigeration-system lineage and installed Danfoss valve.

Machine Fitment

Model-number references below come from the Corbett Equipment FMB / Union / Realstar lineage database and should be verified against the machine data plate and service manual before ordering.

FMB / Firbimatic machine models

• ECOPRO 918

• F AS 18 LT2

• SAVER 40

Union machine models

• HXP8018C

• L840

• P840

Realstar machine models

• KM343

• KM343-K4

• KT343

• KT343-K4

Factory model-code reference: HC7-18-CL

Ordering Verification

Confirm the installed TX2 valve, orifice, refrigerant application, fittings, sensing-bulb arrangement, machine model, and service manual before ordering. Contact Corbett Equipment if you need help matching this valve to a FMB / Firbimatic, Union, Realstar, or related FMB-lineage machine.

Pneumatic Air Switch Dry Cleaning Part 0402002.

Pneumatic air switch 0402002 is used in the air-control system on compatible FMB / Firbimatic, Union, and Realstar dry-cleaning machines.

This switch should be matched by part number, installed component markings, pneumatic line location, mounting style, and machine service manual before ordering.

Use this listing when the installed switch and service records match FMB / Firbimatic 0402002 or legacy reference P1567.

Technical Specifications

• Component type: pneumatic air switch.

• Primary system: pneumatic / air-control circuit.

• Primary application: dry-cleaning machine service and repair.

• Verification points: part number, actuator style, air-line connection, mounting arrangement, and installed component markings.

• Evidence source: Firbimatic parts database/manual evidence for 0402002 and legacy reference P1567.

Part Numbers & Cross References

Part Numbers

FMB / Firbimatic

• 0402002

Union

• Not confirmed in the current Corbett Equipment database. Verify by installed component and service manual.

Realstar

• Not confirmed in the current Corbett Equipment database. Verify by installed component and service manual.

Cross References

FMB / Firbimatic

• Legacy reference P1567

Union

• Verify by shared FMB / Union lineage, installed switch, and Union service manual.

Realstar

• Verify by shared FMB / Realstar lineage, installed switch, and Realstar service manual.

Machine Fitment

Model-number references below come from the Corbett Equipment FMB / Union / Realstar lineage database and should be verified against the machine data plate and service manual before ordering.

FMB / Firbimatic machine models

• ECOPRO 918

• F AS 18 LT2

• SAVER 40

Union machine models

• HXP8018C

• L840

• P840

Realstar machine models

• KM343

• KM343-K4

• KT343

• KT343-K4

Factory model-code reference: HC7-18-CL

Ordering Verification

Confirm the installed switch part number, actuator, pneumatic connections, machine model, and service manual before ordering. Contact Corbett Equipment if you need help matching this switch to a FMB / Firbimatic, Union, Realstar, or related FMB-lineage machine.

Allen Bradley 140M-C2E-B25 Motor Breaker | FMB/Union/Realstar 0323065 is a motor / pump part number 0323065 for pumps / vacuum service work.

Overload 1.6 - 2.5 140M-C2E-B25.

It is organized for professional dry-cleaning equipment repair, with FMB / Firbimatic, Union, and Realstar references shown where the Corbett Equipment database supports the lineage or cross-reference path.

Technical Specifications

• Component type: Motor / pump.

• Primary system: Pumps / vacuum.

• Component type: Pump / motor component.

• Primary application: compatible dry cleaning machine service and repair.

• Catalog category: Dry Cleaning Machine Parts.

• Primary brand line: Firbimatic.

• Evidence status: single brand manual backed.

• Overload 1.6 - 2.5 140M-C2E-B25.

• Catalog application group: review.

• Supported by 5 internal Corbett manual, catalog, or product-evidence hit(s).

• Verify operating ratings, size, connection style, mounting, material, and machine application against the installed component before ordering.

Part Numbers & Cross References

Part Numbers

FMB / Firbimatic

• 0323065

Union

• Verify Union fitment by installed component, manual, and FMB machine lineage.

Realstar

• Verify Realstar fitment by installed component, manual, and FMB machine lineage.

Cross References

Legacy / old FMB references

• No public legacy number is confirmed in the current database.

Component markings

• Use component markings only as verification clues, not as a substitute for machine fitment.

Machine Fitment

Machine fitment is based on Corbett Equipment model-lineage, manual, and part-number evidence. Confirm the installed component, machine data plate, and service manual before ordering.

FMB / Firbimatic machine models

• ECOPRO 918

• F AS 18 LT2

• SAVER 40

• 035

• 05

• 068

• 08

• 09

• 10

• 100

• 12

• 120

• 13

• 130

• 14

• 15

• 153

• 16

• 20

• 208

• 220

• 23

• 24

• 25

Union machine models

• HXP8018C

• L840

• P840

Realstar machine models

• KM343

• KM343-K4

• KT343

• KT343-K4

Factory model-code reference: HC7-18-CL

Ordering Verification

Confirm the part number, installed component markings, voltage or pressure rating where applicable, connection size, mounting style, and machine model before ordering. Contact Corbett Equipment if you need help matching the part to a Firbimatic, Union, Realstar, or related FMB machine.

Nylon Air Valve, 1 in, NO | FMB 0901055 / Union PU090155 / Realstar 0901055 is a valve part number 0901055 for pneumatic / valves service work.

COD 815/32100 1" NO Plastic Valve (Old# V9067).

It is organized for professional dry-cleaning equipment repair, with FMB / Firbimatic, Union, and Realstar references shown where the Corbett Equipment database supports the lineage or cross-reference path.

Technical Specifications

• Component type: Valve.

• Primary system: Pneumatic / valves.

• Component type: Valve / fluid or pneumatic control component.

• Primary application: compatible dry cleaning machine service and repair.

• Catalog category: Valves.

• Primary brand line: Firbimatic.

• Evidence status: not yet manual text backed.

• COD 815/32100 1" NO Plastic Valve (Old# V9067).

• COD 815 1" NO Air Valve (Old# V9067).

• Catalog application group: valves pneumatic.

• Supported by 10 internal Corbett manual, catalog, or product-evidence hit(s).

• Verify operating ratings, size, connection style, mounting, material, and machine application against the installed component before ordering.

Part Numbers & Cross References

Part numbers are grouped by dry-cleaning machine brand. Legacy codes, old FMB numbers, and component markings are kept separate so current ordering numbers are not mixed with verification-only references.

Part Numbers

FMB / Firbimatic

• 0901055

Union

• PU090155

Realstar

• 0901055

Cross References

Legacy / old FMB references

• V9067

Component markings

• COD 32100

• COD 815

Machine Fitment

Machine fitment is based on Corbett Equipment model-lineage, manual, and part-number evidence. Confirm the installed component, machine data plate, and service manual before ordering.

FMB / Firbimatic machine models

• Verify against the FMB / Firbimatic machine data plate and service manual.

Union machine models

• Verify against the Union machine data plate and service manual.

Realstar machine models

• Verify against the Realstar machine data plate and service manual.

Ordering Verification

Confirm the part number, installed component markings, voltage or pressure rating where applicable, connection size, mounting style, and machine model before ordering. Contact Corbett Equipment if you need help matching the part to a Firbimatic, Union, Realstar, or related FMB machine.

VACUUM PUMP MOTOR LIQUID COOLED | FMB / Union / Realstar PU071905 is a motor / pump part number PU071905 for pumps / vacuum service work.

TRMB 32-50 Vacuum Pump 3 HP Liquid Cooled (Old# M17726 & 0719005).

It is organized for professional dry-cleaning equipment repair, with FMB / Firbimatic, Union, and Realstar references shown where the Corbett Equipment database supports the lineage or cross-reference path.

Technical Specifications

• Component type: Motor / pump.

• Primary system: Pumps / vacuum.

• Component type: Pump / motor component.

• Primary application: compatible dry cleaning machine service and repair.

• Catalog category: Pumps & Motors.

• Primary brand line: Firbimatic.

• Evidence status: single brand manual backed.

• TRMB 32-50 Vacuum Pump 3 HP Liquid Cooled (Old# M17726 & 0719005).

• Union Dry Cleaning Part PU071905 VACUUM PUMP MOTOR LIQUID COOLED.

• Supported by 5 internal Corbett manual, catalog, or product-evidence hit(s).

• Verify operating ratings, size, connection style, mounting, material, and machine application against the installed component before ordering.

Part Numbers & Cross References

Part Numbers

FMB / Firbimatic

• PU071905

• 0719005

• 0719053

• 32-50

• 0719015

• 0719070

• 0719142

Union

• PU071905

Realstar

• Verify Realstar fitment by installed component, manual, and FMB machine lineage.

Cross References

Legacy / old FMB references

• M17726

Component markings

• Use component markings only as verification clues, not as a substitute for machine fitment.

Machine Fitment

Machine fitment is based on Corbett Equipment model-lineage, manual, and part-number evidence. Confirm the installed component, machine data plate, and service manual before ordering.

FMB / Firbimatic machine models

• ECOPRO 918

• F AS 18 LT2

• SAVER 40

• 035

• 05

• 068

• 08

• 09

• 10

• 100

• 12

• 120

• 13

• 130

• 14

• 15

• 153

• 16

• 20

• 208

• 220

• 23

• 24

• 25

Union machine models

• HXP8018C

• L840

• P840

Realstar machine models

• KM343

• KM343-K4

• KT343

• KT343-K4

Factory model-code reference: HC7-18-CL

Ordering Verification

Confirm the part number, installed component markings, voltage or pressure rating where applicable, connection size, mounting style, and machine model before ordering. Contact Corbett Equipment if you need help matching the part to a Firbimatic, Union, Realstar, or related FMB machine.
